No. | Name | Prameter | Unit |
| 1 | Max Yield limit Max | 490-1000 | N/mm² |
| 2 | Diameter | ￠5-￠720 | mm |
| 3 | Max Tube thickness | 1-50 | mm |
| 4 | Straightening roller | ||
| 5 | Roller distance | 380-1800 | mm |
| 6 | Throat diameter | ￠130-￠680 | mm |
| 7 | Roller length | 210-1050 | mm |
| 8 | Drive motor | ||
| 9 | Model | Y200L2-6 | |
| 10 | Power | 15-355 | KW |
| 11 | Rotation speed | 710-980 | r/min |
| 12 | Reducer | ||
| 13 | Ratio | 5-20 | |
| 14 | Straightening speed | 12-120 | m/min |
